Some materials are wrapped on the outside of the terminal wire harness, and the type of materials on the outside of the terminal wire varies greatly according to different applications.
1. Terminal wire jacket heat-shrinkable tube packaging material are tightly wrapped around the wire, making making the rough surface smooth, providing heat insulation and electrical insulation. The use of an adhesive backing tube can provide a strong seal to prevent moisture and chemicals from corroding the harness assembly, but requires the use of a hot air gun, which increases production time and may be difficult to apply throughout the seat belt.
2. Terminal wire sleeve tube packaging material is expandable or packageable. The sleeve is easy to install and highly flexible. Woven polyethylene sleeves are popular because they are durable and light, Even at low temperatures, it can maintain complete flexibility in any direction, so that cable assemblies and wire harnesses can be bent repeatedly without damage.
3. Terminal wire jacket spirally wound tube packaging material allows the terminal wire to enter and leave the outer packaging material at multiple points. It also provides a variety of color options for easy identification. For example, orange is commonly used in high-pressure applications.
4. Terminal wire jacket split loom tube packaging material is generally cut down from the side to facilitate the insertion of the terminal wire. After the installation, the cut is closed, and there is no need to shrink or dispense the end. Plastic pipes are usually made of polyamide, polyethylene or polypropylene, however, handling wiring without compression can be cumbersome.
5. The single-sided coated pressure sensitive tape of terminal wire harness jacket tape packaging material can provide various backing materials and pressure sensitive adhesives, and PVC is the most commonly used tape material, but other materials can also be used, including fabric , Felt, foam and aluminum foil, and the tape also maximizes the flexibility of the terminal wire.
