Introduction to Cable Harness Assembly
In the field of automotive wiring harnesses, cable harness assembly plays a crucial role in ensuring the safety of electrical connections inside the vehicle.As a wire harness manufacturers with over 20 years of experience in wire harness manufacturing, ECOCABLES clearly understands that cable harness assembly is the combination of wires and cables to transmit signals and electricity. This transmission process is of great significance to the modern automotive industry, as it encompasses a wide variety of wiring harness systems that require more high-quality cable harness production.
At present, from the perspectives of engineers and purchasers, it is very crucial to find a suitable cable harness supplier. As a professional cable harness manufacturers, ECOCABLES helps you with a one-stop custom wire harness solution, precisely targeting the demands of the automotive industry. Our professional technical knowledge in wire harness assembly guarantees durability in different environments.
Understanding Wire Types in Cable Harness Assembly
Among the wire types of automotive cable harness assembly, there are AEX, AV, AVS and AVSS. These are all low-voltage wires specially designed for the automotive wiring harness field, with a temperature range from -40℃ to over 120℃. In the application of cable harness assembly, choosing the matching wire is crucial for improving efficiency and safety.
As a professional cable and harness manufacturers, ECOCABLES 'harness cable assemblies are mostly made of PVC insulation materials. For example, AVSS wires have a thin insulating layer. In the layout of automotive wiring harnesses, they can save space and are an excellent choice for custom cable harness designs.
Standards and Specifications for Cable Harness Assembly
The standards for vehicle wires include QFR, QVR-105 and QVR, and stipulate that the conductor size should be between 0.5mm² and 5mm² or above. The specifications used in the production of wire harness manufacture must comply with standards to ensure the compliance of automobiles. As a professional wire harness company, ECOCABLES will implement all compliance standards in the manufacturing of cable harness assemblies.
At the same time, there are also insulated wires such as FLR2X-B, FLRY-A and FLRY-B, all of which have strong flexibility and heat resistance. In the practical application of cable harness assembly, these wires can be safely used in a high-temperature environment of 105°C. Our assembly cable technology also pays more attention to high-quality insulation and precise crimping.
The Role of Insulation and Conductors in Cable Harness Assembly
The insulating materials in cable harness assembly, including PVC, PE and PE-X, play a very important role in preventing short circuits in wires and enhance durability. In automotive cable harness assemblies, conductors made of stranded copper generally have better flexibility.
As an outstanding wire and harness manufacturers, ECOCABLES adopts advanced wire harness assembly lines to adapt to different conductor cross-sections, such as from 0.13mm² to 10mm². This processing method ensures high precision in cable harness production and high performance of the vehicle.
Manufacturing Process of Cable Harness Assembly
The manufacturing process of Cable harness assembly generally begins with the cutting and stripping of wires, followed by the crimping of terminals. In our wire harness assembly board, the wiring harness layout is carried out to ensure the accuracy of routing. ECOCABLES excels in the production projects of custom wire harnesses, including insulation resistance and continuity tests.
In some complex automotive systems, cable and harness assembly mainly fixes multiple wires into a combination. As a cable harness supplier, we can provide you with a one-stop solution from design to cable harness assembly.
High-Temperature Resistant Wires in Cable Harness Assembly
Among these wire models, such as AVX, AEX, AEX-F and AVX-F, the maximum temperature resistance can reach up to 120°C. Wires with high heat resistance are crucial in the cable harness assembly for the engine compartment, as high-temperature conditions are usually reached there. In the production of harness cable assembly, we always pay attention to the precautions in actual use to achieve subsequent reliable operation.
CAVS and CAVUS type wires can support ultra-thin insulation, with a standard insulation thickness of 0.2mm, making them suitable for environments with limited space. In wire harness assembly applications, this type of wire speeds up vehicle fuel efficiency and reduces overall weight, which is conducive to lightweight design.
Testing and Quality Control in Cable Harness Assembly
In the manufacturing of cable harness assembly, quality control is a very crucial process. At ECOCABLES, we conduct unified quality monitoring tests, such as environmental simulation tests and tensile tests, etc. As a wire harness manufacturers dedicated to the research of wire harness manufacturing, our strict quality control is the guarantee for us to have many markets in the industry.
Whether you are an engineer or a purchaser, you can refer to our custom cable harness to get what you need to know. Please click on our JST Cable Assembly to view the specific solutions.
Conclusion: Partnering with ECOCABLES for Cable Harness Assembly
Overall, to master the details related to cable harness assembly, it is necessary to have a full understanding of the standards, types and manufacturing processes of wires. ECOCABLES is the cable harness manufacturers you can trust. We provide you with one-stop wire harness manufacture services to save your time and cost.
If you want to receive customized solution services, please contact us here. ECOCABLES possesses professional and standardized cable harness assembly expertise and technology to ensure that each cable harness assembly meets your needs.
